Location > Home > Products > External TV Solutions >FlyTV Express M5 MST T2A2


    Features | Specification | Cable connection chart | System Requirements | Package Contents



Model No. : LR512T2A2

The first true ExpressCard TV tuners in the world, LifeView's ExpressTV solutions are the ultimate in portable multimedia entertainment! With the ExpressCard interface becoming the new standard for laptop PCs, LifeView's ExpressTV solutions are the perfect addition to your new notebook PC! Instead of using the slower USB 2.0 interface, our ExpressTV solutions use the PCI Express interface, which has over five times the bandwidth! Thanks to this increased bandwidth and our exclusive MST technology, you can watch multiple video streams simultaneously!

Watch high quality digital terrestrial (DVB-T) television and analog TV with global compatibility! Watch both digital TV and analog TV at the same time, or record one while watching the other! Use the optional portable antenna and watch TV anywhere - at the park or on the go!






Watch digital terrestrial TV with perfect picture and stereo sound

Supports worldwide analog TV standards
Supports worldwide TV stereo sound standards
Listen to digital terrestrial radio on your PC
Inputs for S-Video and composite video
LifeView MST technology for simultaneous digital and analog video
Record digital video to MPEG-2
Record analog video to MPEG-2
TimeShifting functions let you pause, rewind, and fast forward live TV
Scheduled recording of TV programs
Still image snapshots
EPG and TeleText support
MST: Multiple Streaming Technology
LifeView MST Technology enables you to watch multiple video streams
  simultaneously on one display.
The live video streams can be digital TV and analog video simultaneously,
  S-Video,or composite video.

MST Functionality
PIP (Picture In Picture)
-
Watch digital TV and analog TV/video picture in picture
Twin mode
- Watch digital TV and analog TV/video side by side in identical windows
Scalable
- Resize the video windows to whatever size you want

Swapping
- Swap video between the primary and secondary window with a click of a button











  • CPU: Pentium M 1.7GHz / AMD Athlon 2GHz or faster
  • RAM: 512MB required
  • Microsoft Windows 2000/XP or higher
  • 100 MB HD space for installation, additional space
    required for recording or TimeShifting
  • VGA card/chipset with full DirectX 9.0 support
  • DirectX 9.0c or higher installed
  • Available ExpressCard slot




  • FlyTV Express M5 MST-T2A2
  • Mini RCA to NTSC / Mini RCA to PAL Connectors (x2)
  • AV input cable
  • Portable Antenna (optional)
  • Remote Control (optional)
  • Installation CD with User manual
  • Quick Installation Guide
